plat_pldm_sensor.h File Reference

#include "pdr.h"

Include dependency graph for plat_pldm_sensor.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Macros
#define	ADDR_TMP75_INLET   (0x92 >> 1)
#define	ADDR_TMP75_OUTLET   (0x98 >> 1)
#define	ADDR_TMP75_FIO   (0x90 >> 1)
#define	ADDR_VR_CPU0   (0XEC >> 1)
#define	ADDR_VR_SOC   (0XEC >> 1)
#define	ADDR_VR_CPU1   (0XC6 >> 1)
#define	ADDR_VR_PVDDIO   (0XC6 >> 1)
#define	ADDR_VR_PVDD11   (0XE4 >> 1)
#define	ADDR_X8_INA233   (0x8A >> 1)
#define	ADDR_X16_INA233   (0x82 >> 1)
#define	ADDR_E1S_BOOT_INA233   (0x8A >> 1)
#define	ADDR_E1S_DATA_INA233   (0x80 >> 1)
#define	ADDR_X8_RETIMER   (0x46 >> 1)
#define	ADDR_X16_RETIMER   (0x40 >> 1)
#define	ADDR_NVME   (0xD4 >> 1)
#define	OFFSET_TMP75_TEMP   0x00
#define	OFFSET_NVME_TEMP   0x00
#define	NUM_SOC_PACKAGE_PWR   0x0055
#define	UPDATE_INTERVAL_1S   1
#define	UPDATE_INTERVAL_3S   3
#define	UPDATA_INTERNAL_1HR   3600
#define	VR_DEVICE_UNKNOWN   0xFF
#define	SENSOR_NUM_MB_INA233_E1S_DATA_VOLT_V   0x0033
#define	SENSOR_NUM_MB_INA233_X8_RTM_CURR_A   0x0045
#define	SENSOR_NUM_MB_INA233_E1S_DATA_CURR_A   0x0048
#define	SENSOR_NUM_MB_INA233_X8_RTM_PWR_W   0x0062
#define	SENSOR_NUM_MB_INA233_E1S_DATA_PWR_W   0x0065

Enumerations
enum	SENSOR_THREAD_LIST {   UBC_SENSOR_THREAD_ID = 0 , VR_SENSOR_THREAD_ID , TEMP_SENSOR_THREAD_ID , MAX_SENSOR_THREAD_ID ,   TMP_SENSOR_THREAD_ID = 0 , ADC_SENSOR_THREAD_ID , INA233_SENSOR_THREAD_ID , VR_SENSOR_THREAD_ID ,   DIMM_SENSOR_THREAD_ID , MAX_SENSOR_THREAD_ID , ADC_SENSOR_THREAD_ID = 0 , VR_SENSOR_THREAD_ID ,   MB_TEMP_SENSOR_THREAD_ID , CPU_SENSOR_THREAD_ID , INA233_SENSOR_THREAD_ID , DIMM_SENSOR_THREAD_ID ,   MAX_SENSOR_THREAD_ID , ADC_SENSOR_THREAD_ID = 0 , TMP_SENSOR_THREAD_ID , INA233_SENSOR_THREAD_ID ,   VR_SENSOR_THREAD_ID , DIMM_SENSOR_THREAD_ID , ADC_MONITOR_SENSOR_THREAD_ID , MAX_SENSOR_THREAD_ID }
enum	GET_VR_DEV_STATUS {   GET_VR_DEV_SUCCESS = 0 , GET_VR_DEV_FAILED , GET_VR_DEV_SUCCESS = 0 , GET_VR_DEV_FAILED ,   GET_VR_DEV_SUCCESS = 0 , GET_VR_DEV_FAILED }

Functions
int	plat_pldm_sensor_get_sensor_count (int thread_id)
uint8_t	plat_pldm_sensor_get_vr_dev (uint8_t *vr_dev)
uint8_t	plat_pldm_sensor_get_ina_dev ()
void	plat_pldm_sensor_change_vr_dev ()
void	plat_pldm_sensor_change_ssd_dev ()
void	plat_pldm_sensor_change_cpu_bus ()
void	plat_pldm_sensor_change_retimer_dev ()
void	plat_pldm_sensor_change_ina_dev ()
void	plat_init_pldm_sensor_table ()
void	plat_init_pldm_disabled_sensors ()
void	plat_pldm_sensor_change_dimm_dev ()
void	plat_pldm_sensor_clear_vr_fault (uint8_t vr_addr, uint8_t vr_bus, uint8_t page_cnt)

Macro Definition Documentation

ADDR_E1S_BOOT_INA233

#define ADDR_E1S_BOOT_INA233   (0x8A >> 1)

ADDR_E1S_DATA_INA233

#define ADDR_E1S_DATA_INA233   (0x80 >> 1)

ADDR_NVME

#define ADDR_NVME   (0xD4 >> 1)

ADDR_TMP75_FIO

#define ADDR_TMP75_FIO   (0x90 >> 1)

ADDR_TMP75_INLET

#define ADDR_TMP75_INLET   (0x92 >> 1)

ADDR_TMP75_OUTLET

#define ADDR_TMP75_OUTLET   (0x98 >> 1)

ADDR_VR_CPU0

#define ADDR_VR_CPU0   (0XEC >> 1)

ADDR_VR_CPU1

#define ADDR_VR_CPU1   (0XC6 >> 1)

ADDR_VR_PVDD11

#define ADDR_VR_PVDD11   (0XE4 >> 1)

ADDR_VR_PVDDIO

#define ADDR_VR_PVDDIO   (0XC6 >> 1)

ADDR_VR_SOC

#define ADDR_VR_SOC   (0XEC >> 1)

ADDR_X16_INA233

#define ADDR_X16_INA233   (0x82 >> 1)

ADDR_X16_RETIMER

#define ADDR_X16_RETIMER   (0x40 >> 1)

ADDR_X8_INA233

#define ADDR_X8_INA233   (0x8A >> 1)

ADDR_X8_RETIMER

#define ADDR_X8_RETIMER   (0x46 >> 1)

NUM_SOC_PACKAGE_PWR

#define NUM_SOC_PACKAGE_PWR   0x0055

OFFSET_NVME_TEMP

#define OFFSET_NVME_TEMP   0x00

OFFSET_TMP75_TEMP

#define OFFSET_TMP75_TEMP   0x00

SENSOR_NUM_MB_INA233_E1S_DATA_CURR_A

#define SENSOR_NUM_MB_INA233_E1S_DATA_CURR_A   0x0048

SENSOR_NUM_MB_INA233_E1S_DATA_PWR_W

#define SENSOR_NUM_MB_INA233_E1S_DATA_PWR_W   0x0065

SENSOR_NUM_MB_INA233_E1S_DATA_VOLT_V

#define SENSOR_NUM_MB_INA233_E1S_DATA_VOLT_V   0x0033

SENSOR_NUM_MB_INA233_X8_RTM_CURR_A

#define SENSOR_NUM_MB_INA233_X8_RTM_CURR_A   0x0045

SENSOR_NUM_MB_INA233_X8_RTM_PWR_W

#define SENSOR_NUM_MB_INA233_X8_RTM_PWR_W   0x0062

UPDATA_INTERNAL_1HR

#define UPDATA_INTERNAL_1HR   3600

UPDATE_INTERVAL_1S

#define UPDATE_INTERVAL_1S   1

UPDATE_INTERVAL_3S

#define UPDATE_INTERVAL_3S   3

VR_DEVICE_UNKNOWN

#define VR_DEVICE_UNKNOWN   0xFF

Enumeration Type Documentation

GET_VR_DEV_STATUS

enum GET_VR_DEV_STATUS

Enumerator
GET_VR_DEV_SUCCESS
GET_VR_DEV_FAILED
GET_VR_DEV_SUCCESS
GET_VR_DEV_FAILED
GET_VR_DEV_SUCCESS
GET_VR_DEV_FAILED

SENSOR_THREAD_LIST

enum SENSOR_THREAD_LIST

Enumerator
UBC_SENSOR_THREAD_ID
VR_SENSOR_THREAD_ID
TEMP_SENSOR_THREAD_ID
MAX_SENSOR_THREAD_ID
TMP_SENSOR_THREAD_ID
ADC_SENSOR_THREAD_ID
INA233_SENSOR_THREAD_ID
VR_SENSOR_THREAD_ID
DIMM_SENSOR_THREAD_ID
MAX_SENSOR_THREAD_ID
ADC_SENSOR_THREAD_ID
VR_SENSOR_THREAD_ID
MB_TEMP_SENSOR_THREAD_ID
CPU_SENSOR_THREAD_ID
INA233_SENSOR_THREAD_ID
DIMM_SENSOR_THREAD_ID
MAX_SENSOR_THREAD_ID
ADC_SENSOR_THREAD_ID
TMP_SENSOR_THREAD_ID
INA233_SENSOR_THREAD_ID
VR_SENSOR_THREAD_ID
DIMM_SENSOR_THREAD_ID
ADC_MONITOR_SENSOR_THREAD_ID
MAX_SENSOR_THREAD_ID

Function Documentation

plat_init_pldm_disabled_sensors()

void plat_init_pldm_disabled_sensors

(

)

Here is the call graph for this function:

plat_init_pldm_sensor_table()

void plat_init_pldm_sensor_table

(

)

Here is the call graph for this function:

plat_pldm_sensor_change_cpu_bus()

void plat_pldm_sensor_change_cpu_bus

(

)

plat_pldm_sensor_change_dimm_dev()

void plat_pldm_sensor_change_dimm_dev

(

)

Here is the call graph for this function:

plat_pldm_sensor_change_ina_dev()

void plat_pldm_sensor_change_ina_dev

(

)

Here is the call graph for this function:

plat_pldm_sensor_change_retimer_dev()

void plat_pldm_sensor_change_retimer_dev

(

)

plat_pldm_sensor_change_ssd_dev()

void plat_pldm_sensor_change_ssd_dev

(

)

Here is the call graph for this function:

plat_pldm_sensor_change_vr_dev()

void plat_pldm_sensor_change_vr_dev

(

)

Here is the call graph for this function:

plat_pldm_sensor_clear_vr_fault()

void plat_pldm_sensor_clear_vr_fault	(	uint8_t	vr_addr,
		uint8_t	vr_bus,
		uint8_t	page_cnt
	)

Here is the call graph for this function:

plat_pldm_sensor_get_ina_dev()

uint8_t plat_pldm_sensor_get_ina_dev

(

)

Here is the call graph for this function:

plat_pldm_sensor_get_sensor_count()

int plat_pldm_sensor_get_sensor_count

(

int

thread_id

)

plat_pldm_sensor_get_vr_dev()

uint8_t plat_pldm_sensor_get_vr_dev

(

uint8_t *

vr_dev

)
