#include "hal_gpio.h"

Include dependency graph for plat_gpio.h:

This graph shows which files directly or indirectly include this file:

Macros
#define	name_gpioA

#define	name_gpioB

#define	name_gpioC

#define	name_gpioD

#define	name_gpioE

#define	name_gpioF

#define	name_gpioG

#define	name_gpioH

#define	name_gpioI

#define	name_gpioJ

#define	name_gpioK

#define	name_gpioL

#define	name_gpioM

#define	name_gpioN

#define	name_gpioO

#define	name_gpioP

#define	name_gpioQ

#define	name_gpioR

#define	name_gpioS

#define	name_gpioT

#define	name_gpioU

#define	gpio_name_to_num(x) x,

Enumerations
enum	_GPIO_NUMS_ { name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioF , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU , name_gpioU }

Functions
void	enable_PRDY_interrupt ()

void	disable_PRDY_interrupt ()

Variables
enum _GPIO_NUMS_	GPIO_NUMS

char *	gpio_name []

Macro Definition Documentation

◆ gpio_name_to_num

#define gpio_name_to_num ( x ) x,

◆ name_gpioA

#define name_gpioA

Value:

    gpio_name_to_num(FM_BMC_PCH_SCI_LPC_R_N) \
    gpio_name_to_num(FM_BIOS_POST_CMPLT_BMC_N) \
    gpio_name_to_num(FM_SLPS3_PLD_N) \
    gpio_name_to_num(IRQ_BMC_PCH_SMI_LPC_R_N) \
    gpio_name_to_num(IRQ_UV_DETECT_N) \
    gpio_name_to_num(FM_UV_ADR_TRIGGER_EN_R) \
    gpio_name_to_num(IRQ_SMI_ACTIVE_BMC_N) \
    gpio_name_to_num(HSC_SET_EN_R)

◆ name_gpioB

#define name_gpioB

Value:

    gpio_name_to_num(FM_BIC_RST_RTCRST_R) \
    gpio_name_to_num(RST_USB_HUB_N_R) \
    gpio_name_to_num(A_P3V_BAT_SCALED_EN_R) \
    gpio_name_to_num(FM_SPI_PCH_MASTER_SEL_R) \
    gpio_name_to_num(FM_PCHHOT_N) \
    gpio_name_to_num(FM_SLPS4_PLD_N) \
    gpio_name_to_num(FM_S3M_CPU0_CD_INIT_ERROR) \
    gpio_name_to_num(PWRGD_SYS_PWROK)

◆ name_gpioC

#define name_gpioC

Value:

    gpio_name_to_num(FM_HSC_TIMER) \
    gpio_name_to_num(IRQ_SMB_IO_LVC3_STBY_ALRT_N) \
    gpio_name_to_num(IRQ_CPU0_VRHOT_N) \
    gpio_name_to_num(DBP_CPU_PREQ_BIC_N) \
    gpio_name_to_num(FM_CPU_THERMTRIP_LATCH_LVT3_N) \
    gpio_name_to_num(FM_CPU_SKTOCC_LVT3_PLD_N) \
    gpio_name_to_num(H_CPU_MEMHOT_OUT_LVC3_N) \
    gpio_name_to_num(RST_PLTRST_PLD_N)

◆ name_gpioD

#define name_gpioD

Value:

    gpio_name_to_num(PWRBTN_N) \
    gpio_name_to_num(RST_BMC_R_N) \
    gpio_name_to_num(H_BMC_PRDY_BUF_N) \
    gpio_name_to_num(BMC_READY) \
    gpio_name_to_num(BIC_READY) \
    gpio_name_to_num(FM_RMCA_LVT3_N) \
    gpio_name_to_num(HSC_MUX_SWITCH_R) \
    gpio_name_to_num(FM_FORCE_ADR_N_R)

◆ name_gpioE

#define name_gpioE

Value:

    gpio_name_to_num(PWRGD_CPU_LVC3) \
    gpio_name_to_num(FM_PCH_BMC_THERMTRIP_N) \
    gpio_name_to_num(FM_THROTTLE_R_N) \
    gpio_name_to_num(IRQ_HSC_ALERT2_N) \
    gpio_name_to_num(SMB_SENSOR_LVC3_ALERT_N) \
    gpio_name_to_num(FM_CATERR_LVT3_N) \
    gpio_name_to_num(SYS_PWRBTN_N) \
    gpio_name_to_num(RST_PLTRST_BUF_N)

◆ name_gpioF

#define name_gpioF

Value:

    gpio_name_to_num(IRQ_BMC_PCH_NMI_R) \
    gpio_name_to_num(IRQ_SML1_PMBUS_ALERT_N) \
    gpio_name_to_num(IRQ_PCH_CPU_NMI_EVENT_N) \
    gpio_name_to_num(FM_BMC_DEBUG_ENABLE_N) \
    gpio_name_to_num(FM_DBP_PRESENT_N) \
    gpio_name_to_num(FM_FAST_PROCHOT_EN_N_R) \
    gpio_name_to_num(FM_SPI_MUX_OE_CTL_PLD_N) \
    gpio_name_to_num(FBRK_N_R)

◆ name_gpioG

#define name_gpioG

Value:

    gpio_name_to_num(FM_PEHPCPU_INT) \
    gpio_name_to_num(FM_BIOS_MRC_DEBUG_MSG_DIS_R) \
    gpio_name_to_num(FAST_PROCHOT_N) \
    gpio_name_to_num(FM_JTAG_TCK_MUX_SEL_R) \
    gpio_name_to_num(BMC_JTAG_SEL_R) \
    gpio_name_to_num(H_CPU_ERR0_LVC3_N) \
    gpio_name_to_num(H_CPU_ERR1_LVC3_N) \
    gpio_name_to_num(H_CPU_ERR2_LVC3_N)

◆ name_gpioH

#define name_gpioH

Value:

    gpio_name_to_num(RST_RSMRST_BMC_N) \
    gpio_name_to_num(FM_MP_PS_FAIL_N) \
    gpio_name_to_num(H_CPU_MEMTRIP_LVC3_N) \
    gpio_name_to_num(FM_CPU_BIC_PROCHOT_LVT3_N) \
    gpio_name_to_num(Reserve_GPIOH4) \
    gpio_name_to_num(Reserve_GPIOH5) \
    gpio_name_to_num(Reserve_GPIOH6) \
    gpio_name_to_num(Reserve_GPIOH7)

◆ name_gpioI

#define name_gpioI

Value:

    gpio_name_to_num(Reserve_GPIOI0) \
    gpio_name_to_num(Reserve_GPIOI1) \
    gpio_name_to_num(Reserve_GPIOI2) \
    gpio_name_to_num(Reserve_GPIOI3) \
    gpio_name_to_num(Reserve_GPIOI4) \
    gpio_name_to_num(Reserve_GPIOI5) \
    gpio_name_to_num(Reserve_GPIOI6) \
    gpio_name_to_num(Reserve_GPIOI7)

◆ name_gpioJ

#define name_gpioJ

Value:

    gpio_name_to_num(Reserve_GPIOJ0) \
    gpio_name_to_num(Reserve_GPIOJ1) \
    gpio_name_to_num(Reserve_GPIOJ2) \
    gpio_name_to_num(Reserve_GPIOJ3) \
    gpio_name_to_num(Reserve_GPIOJ4) \
    gpio_name_to_num(Reserve_GPIOJ5) \
    gpio_name_to_num(Reserve_GPIOJ6) \
    gpio_name_to_num(Reserve_GPIOJ7)

◆ name_gpioK

#define name_gpioK

Value:

    gpio_name_to_num(Reserve_GPIOK0) \
    gpio_name_to_num(Reserve_GPIOK1) \
    gpio_name_to_num(Reserve_GPIOK2) \
    gpio_name_to_num(Reserve_GPIOK3) \
    gpio_name_to_num(Reserve_GPIOK4) \
    gpio_name_to_num(Reserve_GPIOK5) \
    gpio_name_to_num(Reserve_GPIOK6) \
    gpio_name_to_num(Reserve_GPIOK7)

◆ name_gpioL

#define name_gpioL

Value:

    gpio_name_to_num(Reserve_GPIOL0) \
    gpio_name_to_num(Reserve_GPIOL1) \
    gpio_name_to_num(Reserve_GPIOL2) \
    gpio_name_to_num(BOARD_ID2) \
    gpio_name_to_num(IRQ_PVCCD_CPU0_VRHOT_LVC3_N) \
    gpio_name_to_num(FM_PVCCIN_CPU0_PWR_IN_ALERT_N) \
    gpio_name_to_num(BOARD_ID0) \
    gpio_name_to_num(BOARD_ID1)

◆ name_gpioM

#define name_gpioM

Value:

    gpio_name_to_num(Reserve_GPIOM0) \
    gpio_name_to_num(BOARD_ID3) \
    gpio_name_to_num(Reserve_GPIOM2) \
    gpio_name_to_num(FM_THROTTLE_IN_N) \
    gpio_name_to_num(AUTH_COMPLETE) \
    gpio_name_to_num(AUTH_PRSNT_N) \
    gpio_name_to_num(Reserve_GPIOM6) \
    gpio_name_to_num(Reserve_GPIOM7)

◆ name_gpioN

#define name_gpioN

Value:

    gpio_name_to_num(SGPIO_BMC_CLK_R) \
    gpio_name_to_num(SGPIO_BMC_LD_R_N) \
    gpio_name_to_num(SGPIO_BMC_DOUT_R) \
    gpio_name_to_num(SGPIO_BMC_DIN) \
    gpio_name_to_num(Reserve_GPION4) \
    gpio_name_to_num(Reserve_GPION5) \
    gpio_name_to_num(Reserve_GPION6) \
    gpio_name_to_num(Reserve_GPION7)

◆ name_gpioO

#define name_gpioO

Value:

    gpio_name_to_num(Reserve_GPIOO0) \
    gpio_name_to_num(Reserve_GPIOO1) \
    gpio_name_to_num(Reserve_GPIOO2) \
    gpio_name_to_num(Reserve_GPIOO3) \
    gpio_name_to_num(Reserve_GPIOO4) \
    gpio_name_to_num(Reserve_GPIOO5) \
    gpio_name_to_num(Reserve_GPIOO6) \
    gpio_name_to_num(Reserve_GPIOO7)

◆ name_gpioP

#define name_gpioP

Value:

    gpio_name_to_num(Reserve_GPIOP0) \
    gpio_name_to_num(Reserve_GPIOP1) \
    gpio_name_to_num(Reserve_GPIOP2) \
    gpio_name_to_num(Reserve_GPIOP3) \
    gpio_name_to_num(Reserve_GPIOP4) \
    gpio_name_to_num(Reserve_GPIOP5) \
    gpio_name_to_num(Reserve_GPIOP6) \
    gpio_name_to_num(Reserve_GPIOP7)

◆ name_gpioQ

#define name_gpioQ

Value:

    gpio_name_to_num(Reserve_GPIOQ0) \
    gpio_name_to_num(Reserve_GPIOQ1) \
    gpio_name_to_num(Reserve_GPIOQ2) \
    gpio_name_to_num(Reserve_GPIOQ3) \
    gpio_name_to_num(Reserve_GPIOQ4) \
    gpio_name_to_num(Reserve_GPIOQ5) \
    gpio_name_to_num(Reserve_GPIOQ6) \
    gpio_name_to_num(Reserve_GPIOQ7)

◆ name_gpioR

#define name_gpioR

Value:

    gpio_name_to_num(Reserve_GPIOR0) \
    gpio_name_to_num(Reserve_GPIOR1) \
    gpio_name_to_num(Reserve_GPIOR2) \
    gpio_name_to_num(Reserve_GPIOR3) \
    gpio_name_to_num(Reserve_GPIOR4) \
    gpio_name_to_num(Reserve_GPIOR5) \
    gpio_name_to_num(Reserve_GPIOR6) \
    gpio_name_to_num(Reserve_GPIOR7)

◆ name_gpioS

#define name_gpioS

Value:

    gpio_name_to_num(Reserve_GPIOS0) \
    gpio_name_to_num(Reserve_GPIOS1) \
    gpio_name_to_num(Reserve_GPIOS2) \
    gpio_name_to_num(Reserve_GPIOS3) \
    gpio_name_to_num(Reserve_GPIOS4) \
    gpio_name_to_num(Reserve_GPIOS5) \
    gpio_name_to_num(Reserve_GPIOS6) \
    gpio_name_to_num(Reserve_GPIOS7)

◆ name_gpioT

#define name_gpioT

Value:

    gpio_name_to_num(Reserve_GPIOT0) \
    gpio_name_to_num(Reserve_GPIOT1) \
    gpio_name_to_num(Reserve_GPIOT2) \
    gpio_name_to_num(Reserve_GPIOT3) \
    gpio_name_to_num(Reserve_GPIOT4) \
    gpio_name_to_num(Reserve_GPIOT5) \
    gpio_name_to_num(Reserve_GPIOT6) \
    gpio_name_to_num(Reserve_GPIOT7)

◆ name_gpioU

#define name_gpioU

Value:

    gpio_name_to_num(Reserve_GPIOU0) \
    gpio_name_to_num(Reserve_GPIOU1) \
    gpio_name_to_num(Reserve_GPIOU2) \
    gpio_name_to_num(Reserve_GPIOU3) \
    gpio_name_to_num(Reserve_GPIOU4) \
    gpio_name_to_num(Reserve_GPIOU5) \
    gpio_name_to_num(Reserve_GPIOU6) \
    gpio_name_to_num(Reserve_GPIOU7)

Enumeration Type Documentation

◆ _GPIO_NUMS_

enum _GPIO_NUMS_

Enumerator
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioF
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU
name_gpioU

Function Documentation

◆ disable_PRDY_interrupt()

void disable_PRDY_interrupt ( )

◆ enable_PRDY_interrupt()

void enable_PRDY_interrupt ( )

Variable Documentation

◆ gpio_name

char* gpio_name[]

extern

◆ GPIO_NUMS

enum _GPIO_NUMS_ GPIO_NUMS

extern
